제품 상세 정보:
|
| Application: | Air Duct System | Function: | Anti-seismic Support |
|---|---|---|---|
| Usage: | Commercial And Industrial Buildings | Package: | Carton Box |
| Oem/Odm: | Available | Fire Resistance: | Yes |
| Keywords: | Strut Channel | Product name: | Duct Seismic Bracing |
Fire Resistance Seismic Bracing System For Commercial Building Ductwork
Duct Seismic Bracing can withstand sudden vibration or impact loads. Through the elastic deformation of the components and energy dissipation at the joints (such as the buffering effect of hinged joints), it reduces the displacement of the ducts during an earthquake (typically controlling the displacement to be ≤ 50mm), maintaining the integrity of the system.
The transverse diagonal braces restrict the vertical swaying of the duct along the axis direction, while the longitudinal diagonal braces control the displacement along the axis. Together with the vertical supports, they form a spatial constraint system to ensure that the duct is constrained in all three axes (X, Y, and Z).
| Product Name | Seismic Duct Clamp |
| Function | Anti-seismic Support |
| Adjustable | Yes |
| Weight | 1.95kg |
| Processing Service |
Bending, Welding, Punching, Decoiling, Cutting |
| Corrosion Resistance | Yes |
| Installation | Easy And Quick |
| Package | Carton Box |
| Uses |
Pipe, duct , cable tray support |
| Material | Galvanized Steel |
| Size | Customization |
| Other Names | Tremor Proof Duct Mounting Bracket, Ventilation pipe hanger |
Sensitive scenario: In places like hospital operating rooms and data centers, the duct system is required to continue operating during an earthquake. Anti-seismic brackets can ensure that the ventilation and air conditioning systems do not stop;
Underground scenario: If the ducts fall in subway tunnels, it can easily cause traffic disruption. Anti-seismic brackets ensure the safety of the pipelines in the tunnels by maintaining a fixed spacing (usually ≤ 6m).
Product Packaging:
The Seismic Bracing for Ductwork comes in a sturdy cardboard box that is designed to protect the product during shipping and storage. The box measures 12 inches by 8 inches by 6 inches and weighs approximately 2 pounds. Inside the box, the product is securely packed with foam inserts to prevent any damage during transit.
Shipping:
We offer standard shipping for the Seismic Bracing for Ductwork product. Orders are processed within 24 hours and shipped within 2-3 business days. Shipping rates are calculated at checkout based on the destination and shipping method selected. We ship to all US states and territories, as well as select international locations. Customers can track their shipments using the tracking number provided in the shipping confirmation email.
What is the place of origin of the Seismic Bracing for Ductwork?
The Seismic Bracing for Ductwork is manufactured in Hebei, China.
2.Is the Seismic Bracing for Ductwork certified?
Yes, the Seismic Bracing for Ductwork is certified with ISO9001.
3.What is the minimum order quantity for the Seismic Bracing for Ductwork?
The minimum order quantity for the Seismic Bracing for Ductwork is negotiable.
4.How much does the Seismic Bracing for Ductwork cost?
The price of the Seismic Bracing for Ductwork is negotiable.
5.What is the delivery time for the Seismic Bracing for Ductwork?
The delivery time for the Seismic Bracing for Ductwork is 15-30 work days.
